規格型號
Specification and Model |
SJNⅡ500 |
SJNⅡ1000 |
SJNⅡ1500 |
SJNⅡ2000 |
SJNⅡ3000 |
真空室容積
Vacuum chamber volume (m3) |
1 |
1.5 |
2 |
2.5 |
3.5 |
受液槽容積
Volume of the liquid reservoir (m3) |
0.3 |
0.5 |
0.8 |
1.0 |
1.2 |
回收酒精濃度
Reclaimed alcohol concentration |
85% |
85% |
85% |
85% |
85% |
最大蒸發量
Maximum evaporation rate (kg/h) |
500 |
1000 |
1500 |
2000 |
3000 |
蒸汽壓
vapour pressure
(Mpa) |
0.03-0.09 |
0.03-0.09 |
0.03-0.09 |
0.03-0.09 |
0.03-0.09 |
蒸汽耗量
steam consumption (kg/h) |
250 |
500 |
750 |
1000 |
1500 |
水耗量
Water consumption (t/h) |
5 |
10 |
15 |
15 |
25 |
外加熱器加熱面積
Heating area of the external heater (m2) |
8 |
10 |
16 |
22 |
28 |
二效二次冷凝面積
The area of the second-stage secondary condensation (m2) |
16 |
20 |
26 |
32 |
38 |
蒸汽管口
Steam pipe outlet (mm) |
40 |
50 |
50 |
65 |
80 |
冷卻水管口
Cooling water outlet(mm) |
50 |
50 |
65 |
65 |
65 |
外形尺寸
boundary dimension
|
長length (L) |
4000 |
5000 |
6000 |
6500 |
7500 |
寬wide (M) |
1500 |
1600 |
1600 |
1700 |
2000 |
高
high(H) |
3300 |
3500 |
3700 |
4300 |
4500 |
蒸發溫度
vaporization point
|
一效One effect |
80-90 |
80-90 |
80-90 |
80-90 |
80-90 |
二效Two-stage effect |
45-70 |
45-70 |
45-70 |
45-70 |
45-70 |
設計壓力
design pressure
|
0.09 |
0.09 |
0.09 |
0.09 |
0.09 |
真空度
vacuum degree
|
一效One effect |
0.04 |
0.04 |
0.04 |
0.04 |
0.04 |
二效Two-stage effect |
0.06 |
0.06 |
0.06 |
0.06 |
0.06 |
濃縮比
concentration ratio
|
1.1-1.3 |
1.1-1.3 |
1.1-1.3 |
1.1-1.3 |
1.1-1.3 |
